LED PRODUCT LED

AP 3.9

초경량 Black LED

제품 스펙

PRODUCT	500 x 1000 x 80.4	500 x 500 x 80.4
Pixel Pitch	3.91mm	3.91mm
Pixel matrix per panel	128 x 256 pixel	128 x 128 pixel
Brightness	1000 cd /m²	1000 cd /m²
Cabinet Weight	About 8.9kg	About 5.4kg
Refresh rate	7,680Hz	7,680Hz
Greyscale	16bit	16bit
Viewing Angle	160 / 160 H / V (°)	160 / 160 H / V (°)
Contrast Ratio	10000:1	10000:1
Color Temperature-(Default, Adjustable)	3,500-9,000K adjustable(default 6500K)	3,500-9,000K adjustable(default 6500K)
AC Operating Voltage	100V~240V, AC 50~60Hz	100V~240V, AC 50~60Hz
Power Maximum Value	About 540W/h/m2	About 540W/h/m2
Power Typical Value	About 180W/h/m2	About 180W/h/m2
Operationg Temperature	-10°C ~ +45°C	-10°C ~ +45°C
Operationg Humidity	10%~90% RH	10%~90% RH
IP Rate	IP30	IP30
Maximum hanging system height	15M
Maximum stacking system height	10M
