회사소개서CREATIVE INNOVATION. LDS.PRODUCT
제품 스펙
| PRODUCT | 500 x 1000 x 102 | 500 x 500 x 102 |
|---|---|---|
| Pixel Pitch | 4.8mm | 4.8mm |
| Pixel matrix per panel | 104 x 208 pixel | 104 x 104 pixel |
| Brightness | 4500cd /m² | 4500cd /m² |
| Cabinet Weight | About 12.5kg | About 8kg |
| Refresh rate | 3840Hz above | 3840Hz above |
| Greyscale | 14~16bit | 14~16bit |
| Viewing Angle | 140 / 120 H / V (°) | 140 / 120 H / V (°) |
| AC Operating Voltage | 220V~240V, 50~60Hz | 220V~240V, 50~60Hz |
| Power Maximum Value | 600 W / Tile | 300 W / Tile |
| Power Typical Value | 400 W / Tile | 200 W / Tile |
| Operationg Temperature | -20°C~+40°C | -10°C~+45°C |
| Operationg Humidity | 10%~95% RH | 10%~95% RH |
| IP Rate | Waterproof Front IP65 / Rear IP54 | Waterproof Front IP65 / Rear IP54 |
해당 제품이 사용된 쇼케이스
